Volumetric volume (L): 540 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Fixation point(s): plastic Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Position of…
Additional information: yeast tank in a brewery; cone height appr. 1.300 mm Volumetric volume (L): 13.700 L Pressure in tank: pressure Max. pressure (Bar): 1 Bar Max. temperature (°C): 20 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 40 L Max…
Additional information: condensate tank in a brewery; manhole appr. 340 x 420 mm; some residues of previous content; dents at the insulation jacket; pipe end cut flush Volumetric volume (L): 650 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 180 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile…
Additional information: food colours; cylinder can only be heated in the lower area; 1 distillation column / heat exchanger made of V2A are included (see photos; not taken into account in the total height); some residues of previous content; bump at the insulation jacket; manhole cover plated Volumetric volume (L): 1.750 L Pressure in tank: vacuum Min. pressure (Bar): 1…
Additional information: rennet-production; Feet originally stood on load cells, these are no longer available (see pictures); according to the type plate, the heating coil is designed for an operating pressure of 3 bar at a temperature of - 5 ° C (see photos on the type plate); diameter manhole 430 mm; suspension of manhole cover incomplete Volumetric volume (L): 3.500…
Additional information: rennet-production; smaller dents in the cylinder; small rectangular sheets were welded in by the previous operator in several places of the cylinder; some residues of previous content Volumetric volume (L): 12.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total…
Additional information: pharmacy; Total height including foot pedestals and engine cladding; Double outlet diameter tube inside approx. 35 mm; Insulation jacket with slight damage; 1 crack in the upper double jacket connection Volumetric volume (L): 2.130 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 140 °C Material wet…
Additional information: chemistry; tank mounting: traverse Fe; outlet fitting incomplete; manhole cover is missing Volumetric volume (L): 7.250 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 100 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Max Overpressure: 5 Bar Max.…
Additional information: pharmacy; handhole DN 200; some residues of previous content Volumetric volume (L): 1.333 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 143 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total…
Additional information: pharmacy; internal (moveable) fixtures; the outlet was probably fitted with a fitting, but this is no longer available (see photos) Volumetric volume (L): 650 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing…
Additional information: adhesive production; former support brackets were cut off by dismantling and are not available anymore; 1 heating connection cut off; tank with stronger adhesions; manhole cover plated Volumetric volume (L): 1.100 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile…
Additional information: adhesive production; total height incl. foot frame; foot frame Fe (lacquered); some residues of previous content Volumetric volume (L): 2.300 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate…
