Additional information: Chemistry; 4 loose foot extensions made of stainless steel are included; some residues of previous content; Metallic discolouration inside Volumetric volume (L): 2.500 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with…
Additional information: Chemistry; 4 support brackets made of Fe; 1 vessel with insulation (insulation jacket Fe, lacquered; diameter outside approx. 1780 mm); some residues of previous content; Metallic discolouration inside Volumetric volume (L): 3.685 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS…
Additional information: Pharmaceutical chemistry; 2 support brackets made of Aisi 304 (contact surface the other way around; see photos); flanges partly made of Fe Volumetric volume (L): 1.345 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat…
Additional information: Pharmaceutical chemistry; 2 support brackets made of Aisi 304 (contact surface the other way around; see photos); flanges partly made of Fe; further techn. documents available; bump at the insulation jacket Volumetric volume (L): 1.345 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material…
Additional information: Chemistry; Half-coils cylinder only in the lower cylinder area; some residues of previous content Volumetric volume (L): 4.500 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Max Overpressure: 6 Bar Type HE on the…
Additional information: Chemistry; Manhole diameter approx. 410 mm; 1 baffle inside over the outlet; insulation around the cylinder; some residues of previous content Volumetric volume (L): 850 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total discharge: yes Documents included: no Technical…
Additional information: Chemistry; Insulation around the upper bottom; support ring made of Fe; drawing not available; diameter manhole 470 mm Volumetric volume (L): 8.651 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat…
Additional information: Brine tank (water / salt solution) in a chemical plant; Manhole cylinder DN 600; double outlet DN 50; some residues of previous content Volumetric volume (L): 10.800 L Pressure in tank: pressure Max. pressure (Bar): 3,20 Bar Max. temperature (°C): 100 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no…
Additional information: food industry; tank cover made of 1.4301 (Aisi 304); some residues of previous content Volumetric volume (L): 700 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the…
Additional information: food industry; adhesions and metallic discolourations inside the tank; tank cover made of 1.4301 (aisi 304); motor-/gear is missing Volumetric volume (L): 1.100 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 134 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge:…
Volumetric volume (L): 1.150 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: open Total discharge: yes Fixation point(s): plastic Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Outlet of tank: DN50…
Volumetric volume (L): 550 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: open Total discharge: yes Fixation point(s): plastic Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator:…
