Additional information: chemistry; 3 support brackets Fe; screws of the upper bottom flange are mostly missing; motor-/gear is missing Volumetric volume (L): 720 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no…
Additional information: chemistry; support ring and vessel flange made of mild steel; handholecover cladded Volumetric volume (L): 630 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 300 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile…
Additional information: plastics industry; stronger adhesions inside; working pressure according to drawing (type plate not available); various changes of the connections by the former operator (not shown in the drawing); foot frame, 304 Volumetric volume (L): 396 L Pressure in tank: pressure Max. pressure (Bar): 3 Bar Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger…
Additional information: plastics industry; a number of connections were changed by the former operator; 1 overflow pipe inside; mounting of the manhole cover incomplete; 1 smaller dent inside the tank; some residues of previous content; dents at the insulation jacket Volumetric volume (L): 540 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1…
Additional information: pharmacy; upper bottom made of Aisi 304 (1.4541); metallic discolourations inside; manhole in the upper bottom diameter 350 mm; some residues of previous content; dents at the insulation jacket Volumetric volume (L): 750 L Pressure in tank: pressure Max. pressure (Bar): 2,50 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration:…
Additional information: bitumen; support brackets made of mild steel; some residues of previous content Volumetric volume (L): 100 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Type HE on the cylinder: half pipe welded onto the…
Additional information: pharmacy; according to a sticker of the former operator max. working pressure 1,1 bar; 1 dent in the insulation jacket; insulation jacket of the lower bottom as well as counterweight of the upper bottom made of Fe; hand lever of the outlet valve is missing Volumetric volume (L): 200 L Pressure in tank: ATM - atmosferic Material wet…
Additional information: chemistry Volumetric volume (L): 900 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Outlet of tank: flange DN40 Top: 4…
Additional information: cosmetic; Cone height approx. 800 mm; 1 hand hole diameter 350 mm in the upper bottom; 1 small dent in one of the feet (see photos); some residues of previous content Volumetric volume (L): 3.660 L Pressure in tank: pressure Max. pressure (Bar): 3 Bar Max. temperature (°C): 85 °C Material wet parts: SS AISI 316 (V4A) Model:…
Additional information: pharmacy; The vessel was originally mobile on 4 plastic rollers, these are no longer available; For installation, the rollers would either have to be replaced on site or the feet would have to be set higher accordingly, as the lower bottom / outlet extends beyond the foot end; dents at the insulation jacket; scratches inside Volumetric volume (L):…
Additional information: transport tank for viscous gels; Technical drawing includes structural changes Volumetric volume (L): 2.700 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 0,99 Bar Min. pressure (Bar): 0,50 Bar Max. temperature (°C): 50 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total…
Additional information: chemistry; mild steel parts outside sandblasted and primed; upper bottom heat-/coolable as well; some residues of previous content Volumetric volume (L): 3.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Type HE on the…
