4000 liter tank i Rostfritt 304

Article type: second-hand storage tank Volumetric volume (L): 4.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Top type: dished Shape of tank: cylindrical Bottom type: dished Bottom outlet: yes Total discharge: yes Fixation points: 3 non adjustable feet Type of HE on the cylinder: dimple-jacket Position HE: the middle part of the cilinder Manway(s): RVS 304 Gasket manway(s): unknown Fixation point(s): RVS 304 Suitable for food industry: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Number of manways: 1 Position of manway: cylinder Height manhole 1 (mm): 330 mm x H 430 mm Tank outlet: inside Ø Outlet of tank: DN40 Agitator: no Distance from outlet to ground: 145 mm Outer diameter tank: 1.210 mm Cylinder height: 3.460 mm Total height of tank: 4.000 mm Empty weight tank: 800
