Additional information: Pet food; Attention: Manhole cover in cylinder and agitator shaft made of stainless steel 304; 1 hand hole in upper bottom diameter approx. 200 mm; some residues of previous content Volumetric volume (L): 2.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes…
Additional information: Original calculation overpressure of the inner tank according to technical documents 5.4 bar (test overpressure 8.2 bar); agitator in the manhole cover was probably retrofitted by the previous operator; some residues of previous content Volumetric volume (L): 2.500 L Pressure in tank: pressure Max. pressure (Bar): 5,40 Bar Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration:…
Additional information: 2 stainless steel bearing shells; 1 manhole diameter approx. 600 mm in the front base; 1 manhole approx. 400 mm on the vessel; double jacket only around the lower cylinder area (upper heating connections cut off); connection in the manhole cover of the front base was probably used as an outlet by the previous operator; some residues of…
Additional information: Manhole DN 500 (screws of the manhole cover missing); various technical documents available; ; manhole cover plated Volumetric volume (L): 6.300 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat…
Additional information: The pressure tank has a heating/cooling jacket, but this is leaking in several places (see photos); defect heating jacket Volumetric volume (L): 41.700 L Pressure in tank: pressure Max. pressure (Bar): 4 Bar Max. temperature (°C): 165 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile…
Additional information: Biopharma; Thermoplate only installed in the lower two thirds (see photos); matching feet can be manufactured as an option for an extra charge Volumetric volume (L): 10.800 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 304 (V2A) Model: vertical…
Additional information: Biopharma; 3 specially made feet are included Volumetric volume (L): 1.300 L Pressure in tank: pressure Max. pressure (Bar): 3 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 13 L Max Overpressure: 10 Bar…
Additional information: Biopharma; 3 specially manufactured feet (see pictures) included, optional control unit (see pictures) available at an extra charge Volumetric volume (L): 900 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger…
Additional information: Food; Double jacket with trickle ring - only suitable for unpressurized temperature control Volumetric volume (L): 16.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Type HE on the bottom: heating/cooling jacket Type HE…
Additional information: Pharmacy; Tank lid made of 1.4404 (stainless steel 316) Volumetric volume (L): 72 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 2,50 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total…
Additional information: Chemistry Volumetric volume (L): 10.000 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 20 L Max Overpressure: 3 Bar Max. working temperature: 80 °C Documents included: no Technical…
Additional information: Chemistry; Tempering only in the lower area of the cylinder & underbody (see pictures); manhole cover VA-plated Volumetric volume (L): 33.725 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 140 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat…
