Additional information: Pet food; Small dents in the insulating jacket; some residues of previous content Volumetric volume (L): 3.000 L Pressure in tank: pressure Max. pressure (Bar): 0,40 Bar Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Max Overpressure: 4 Bar Max. working temperature:…
Additional information: Biotech; 4 feet bolted to height-adjustable stainless steel weighing pallet; hand hole DN 200; an identical second vessel can be offered on request Volumetric volume (L): 1.600 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 160 °C Material wet parts: SS AISI 316 (V4A) Model: vertical…
Additional information: Food Volumetric volume (L): 3.200 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Max Overpressure: 3 Bar Max onderdruk: 1…
Additional information: The pressure tank has a heating/cooling jacket, but this is leaking in several places (see photos); defect heating jacket Volumetric volume (L): 41.700 L Pressure in tank: pressure Max. pressure (Bar): 4 Bar Max. temperature (°C): 165 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile…
Additional information: Biopharma; Thermoplate only installed in the lower two thirds (see photos); matching feet can be manufactured as an option for an extra charge Volumetric volume (L): 10.800 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 304 (V2A) Model: vertical…
Additional information: Biopharma; 3 specially made feet are included Volumetric volume (L): 1.300 L Pressure in tank: pressure Max. pressure (Bar): 3 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 13 L Max Overpressure: 10 Bar…
Additional information: Biopharma; 3 specially manufactured feet (see pictures) included, optional control unit (see pictures) available at an extra charge Volumetric volume (L): 900 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger…
Additional information: Food; Double jacket with trickle ring - only suitable for unpressurized temperature control Volumetric volume (L): 16.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Type HE on the bottom: heating/cooling jacket Type HE…
Additional information: Rainwater; some residues of previous content Volumetric volume (L): 1.100 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 1,99 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 130 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume: 122…
Additional information: Pharmacy; Tank lid made of 1.4404 (stainless steel 316) Volumetric volume (L): 72 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 2,50 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total…
Additional information: Brewery Volumetric volume (L): 3.000 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Max. temperature (°C): 134 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Max Overpressure: 2 Bar Max. working temperature: 134 °C Documents included: no Technical drawing…
Additional information: Food; including loose base frame (see pictures) Volumetric volume (L): 7.000 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 50 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume: 150 L Max Overpressure: 3 Bar Max. working temperature: 90…
