730 liter tank i Syrafast 316

Additional information: Pharmaceutical chemistry; Half-coil for heating/cooling around the lower cylindrical area and the lower bottom; hand hole diameter 150 mm; outlet fitting incomplete; Device for load cells under the feet (probably 3 load cells available; loose load cells were not taken into account when specifying the total height), insulation jacket partially cut open in the area of the lower bottom; Technical documents are available from the manufacturer and could be purchased directly from the manufacturer if required; bump at the insulation jacket; handhole cover is missing Volumetric volume (L): 730 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 4 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume: 12 L Max Overpressure: 16 Bar Max onderdruk: 1 Bar Max. working temperature: 200 °C Type HE on the bottom: half pipe welded onto the outside of the innertank Type HE on the cylinder: half pipe welded onto the outside of the innertank Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Outlet of tank: 53 Agitator: yes Number of revolutions: 270 Power: 1,50 Internal diameter tank: 790 mm Outer diameter tank: 1.080 mm Cylinder height: 1.200 mm Total height of tank: 2.950 mm Empty weight tank: 700
