Additional information: Chemistry; DN 500 manhole (manhole cover bolts mostly missing); flanges mostly made of Fe; some residues of previous content; manhole cover plated Volumetric volume (L): 4.413 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration:…
Additional information: Biotech; 4 feet bolted to height-adjustable weighing pallet made of stainless steel 304; hand hole DN 200 Volumetric volume (L): 2.740 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 130 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger:…
Additional information: Manhole DN 500 (screws of the manhole cover missing); various technical documents available; ; manhole cover plated Volumetric volume (L): 6.300 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat…
Additional information: Pharmacy; Hand hole NW 250; 1 small dent in one of the feet (see photos); some residues of previous content Volumetric volume (L): 900 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile…
Additional information: Biotech; 4 feet bolted to height-adjustable stainless steel weighing pallet; hand hole DN 200; an identical second vessel can be offered on request Volumetric volume (L): 1.600 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 160 °C Material wet parts: SS AISI 316 (V4A) Model: vertical…
Additional information: Food Volumetric volume (L): 3.200 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Max Overpressure: 3 Bar Max onderdruk: 1…
Additional information: Pharmacy; Hand hole DN 150; foot ends cut off Volumetric volume (L): 348 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,50 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents…
Additional information: Pharmacy; Manhole DN 450; outlet flange DN 15; crane lugs cut off Volumetric volume (L): 536 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 130 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total…
Additional information: Pharmacy; Outlet NW 40; hand hole NW 150; some residues of previous content Volumetric volume (L): 350 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 100 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no…
Additional information: Biopharma; Thermoplate only installed in the lower two thirds (see photos); matching feet can be manufactured as an option for an extra charge Volumetric volume (L): 10.800 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 304 (V2A) Model: vertical…
Additional information: Biopharma; Matching feet can be manufactured as an option for an additional charge Volumetric volume (L): 10.000 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no…
Additional information: Biopharma; 3 specially manufactured feet (see pictures) included, optional control unit (see pictures) available at an extra charge Volumetric volume (L): 900 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger…
