Additional information: 4 support brackets, Fe; cone height appr. 1400 mm; 2 open connections in the cylinder (see photos); some residues of previous content Volumetric volume (L): 15.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no…
Additional information: fruit juice industry; Manhole appr. 345 x 440 mm; Wall thickness of the lowest cylinder segment: approx. 4.0 mm; pipe end cut flush Volumetric volume (L): 25.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included:…
Additional information: Food Volumetric volume (L): 30.000 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Position of…
item available on order Article type: brand new storage tank - type TZN-SL Volumetric volume (L): 32.000 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2B Pressure in tank: ATM - atmosferic Max. temperature (°C): 60 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 304L (V2A) Model: vertical Configuration: single-skin Heat exchanger:…
Article type: second-hand storage tank Additional information: The tank has never been used. Volumetric volume (L): 32.000 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2B Pressure in tank: ATM - atmosferic Max. temperature (°C): 60 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 304L (V2A) Model: vertical Configuration: single-skin Heat exchanger:…
Additional information: Sterile tank in a dairy; Double jacket with trickle ring - only suitable for unpressurized tempering; dents in the double jacket in the area of the support timbers; maximum temperature for sterilization in the inner tank 145° C; specified total height according to drawing; 1 former connection in the upper bottom was welded shut by the previous operator…
item available on order Article type: brand new storage tank - type TZN-SL Volumetric volume (L): 32.700 L Max. density P (kg/m³): 1.000 Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: conical 13 ° Shape of tank: cylindrical Bottom type: conical…
item available on order Article type: brand new storage tank - type TZN-SL Volumetric volume (L): 32.700 L Max. density P (kg/m³): 1.000 Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316L (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: conical 13 ° Shape of tank: cylindrical Bottom type: conical…
item available on order Article type: brand new storage tank - type TZN-SL Volumetric volume (L): 32.700 L Max. density P (kg/m³): 1.200 Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316L (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: conical 15 ° Shape of tank: cylindrical Bottom type: conical…
Article type: second-hand storage tank Additional information: The tank has never been used. Volumetric volume (L): 32.700 L Max. density P (kg/m³): 1.200 Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316L (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: conical 15 ° Shape of tank: cylindrical Bottom type: conical…
item available on order Article type: brand new storage tank - type TZN-SL Volumetric volume (L): 32.700 L Max. density P (kg/m³): 1.000 Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316L (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: conical 15 ° Shape of tank: cylindrical Bottom type: conical…
