Article type: second-hand mixing tank
Additional information: we can’t give any guarantees about the agitator
Volumetric volume (L): 7.000 L
Pressure in tank: ATM - atmosferic
Material wet parts: SS AISI 304 (V2A)
Model: vertical
Configuration: insulated
Heat exchanger: no
Insulation: yes
Mobile tank: no
Top type: conical
Shape of tank: cylindrical
Bottom type: conical
Total discharge: yes
Fixation points: 3 non adjustable feet
Insulation material: Rockwool
Outer jacket (ornamental wall): RVS 304
Manway(s): RVS 304
Gasket manway(s): unknown
Fixation point(s): RVS 304
Suitable for food industry: yes
Documents included: no
Technical drawing included: no
Registration plate on the tank: no
Flange for agitator: no
Number of manways: 1
Position of manway: at the top
Total outlet valve: yes
Agitator: yes
Agitator type: propeller agitator
Position engine: at the top
Voltage: three-phase
Insulation body: yes
Insulation bottom/sides: yes
finish of the outer jacket: welded
Insulation thickness: 50
Outer diameter tank: 1.800 mm
Cylinder height: 3.500 mm
Empty weight tank: 800
