Additional information: Pharmaceutical chemistry; Material 1.4462 (duplex steel); 1 manhole DN 600 in the cylinder, 2 manholes DN 600 in the upper bottom (in these two manhole covers there are level indicators and pipes); vessel inside with corrosion; sheet metal cut-outs and minor dents in the riveted insulating jacket (hardly avoidable due to dismantling and transport); bump at the insulation…
Additional information: Pharmaceutical chemistry; Wall thickness of the lower bottom of the upper tank 11 mm Volumetric volume (L): 27.300 L Pressure in tank: vacuum Min. pressure (Bar): 0,60 Bar Max. temperature (°C): 50 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no…
Additional information: Feed industry; Manhole appr. 325 x 440 mm; smaller dents in the cylinder Volumetric volume (L): 13.000 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 50 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no…
Additional information: Pharmacy; Mobile Frame, AISI 304 (the control cabinet boxes shown in the photos are empty); smaller dents inside the tanks; Upper bottoms, Aisi 304 (hangings and fastening screws of the upper bottoms are missing); pipe end cut flush; Metallic discolouration inside Volumetric volume (L): 313 L Pressure in tank: pressure Max. pressure (Bar): 3 Bar Max. temperature (°C):…
Additional information: Biomass; Cone height appr. 400 mm; 3-legged frame, Aisi 304; 3 short pipes inside the tank Volumetric volume (L): 400 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate…
Additional information: Pharmacy; Frame made of AISI304/316; Manhole diameter approx. 455 mm (Manhole cover and clamping ring only available for 1 container); 1 opening at the cone end, diameter approx. 600 mm (closures no longer available); 1 container with side connections (see photos) Volumetric volume (L): 1.900 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316…
Additional information: Spirits; 5 loose plug-in feet made of Fe; manhole approx. 320 x 420 mm; stronger adhesions inside the tanks; 1 tank with dents in the upper bottom; the hand lever of the butterfly valve is missing on 1 tank Volumetric volume (L): 9.500 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model:…
Additional information: Pharmacy; Slight differences in the design of the vessels; differences in the connections in the manhole cover; overall height slightly lower in some cases (depending on the connections in the manhole cover) Volumetric volume (L): 500 L Pressure in tank: pressure Max. pressure (Bar): 3 Bar Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat…
Additional information: Smaller dents in the insulation jacket; 2 hand holes with a diameter of approx. 175 mm each and 1 elongated sheet metal cutout in the lid (see photos); some residues of previous content Volumetric volume (L): 850 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no…
Additional information: Brewery; According to information from the previous operator, the tanks were last used as fermentation tanks in a brewery with an operating pressure of +2 bar. According to the drawing, the tanks were tested with a test pressure of +4 bar. However, a TÜV test was not carried out; Diameter manhole 350 mm; 1 tank is missing 1…
Additional information: Dairy; 1 manhole diamter 500 mm in the front bottom Volumetric volume (L): 3.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: horizontal Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for…
Additional information: Tank hanging on 3 "feet" in frame or ceiling; Hand hole diameter approx. 300 mm; Outlet fitting is missing; some residues of previous content Volumetric volume (L): 324 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 134 °C Material wet parts: SS AISI 316 (V4A) Model:…
Additional information: Pharmacy; Foot frame, 304; slight differences in design; the manhole cover is missing in 2 containers, and the clamping ring of the manhole cover is missing in the third container; traces of usage Volumetric volume (L): 1.950 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no…
Additional information: Cip-tank in a dairy; Manhole diameter 420 mm; 1 tank slightly lower in total height; Butterfly valves of the outlets defective; Various pipes on the tanks (mostly cut off); some residues of previous content Volumetric volume (L): 6.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger:…
Article type: second-hand pressure tank Additional information: Pharmacy; scratches inside Volumetric volume (L): 568 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 2 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 134 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge:…
Additional information: 1 stronger and smaller dents in the insulation jacket; lower heating connection cut off; some residues of previous content; pipe end cut flush; scratches inside; Functionality of the double jacket not checked Volumetric volume (L): 350 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger:…
Additional information: Manhole diameter approx. 440 mm (manhole cover is loose); tank with small dents; some residues of previous content Volumetric volume (L): 1.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no…
Additional information: Frame, Fe; Tank open at the top with a loose lid segment (see photos) Volumetric volume (L): 1.100 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the…
Additional information: Spirits; Adhesions and metallic discoloration inside the tank; lower bottom with smaller dents Volumetric volume (L): 1.700 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank:…
Additional information: Spirits; Manhole appr. 320 x 425 mm (Fastening of the manhole cover incomplete) Volumetric volume (L): 1.200 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank:…
Additional information: Lacquers; Manhole diameter 500 mm; Small dents in the cylinder; Differences in the outlet sizes possible; some residues of previous content Volumetric volume (L): 10.600 L Pressure in tank: pressure Max. pressure (Bar): 0,50 Bar Max. temperature (°C): 100 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank:…
Additional information: Brewery; some residues of previous content; Metallic discolouration inside Volumetric volume (L): 24.400 L Pressure in tank: pressure Max. pressure (Bar): 4 Bar Max. temperature (°C): 20 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 114 L Max Overpressure:…
Additional information: Ethanol; 1 manhole approx. 340 x 440 in the front bottom; Test pressure according to the nameplate 2 bar; some residues of previous content Volumetric volume (L): 2.645 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: horizontal Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents…
Additional information: Food industry; According to the nameplate operating pressure 1 bar; However, the nameplate is only present on some of the containers; slight differences in the design of the container (e.g. manhole cover; feet); Container with some (smaller) dents; some residues of previous content; traces of usage Volumetric volume (L): 800 L Pressure in tank: ATM - atmosferic Material…
