Additional information: Brewery Volumetric volume (L): 3.000 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Max. temperature (°C): 134 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Max Overpressure: 2 Bar Max. working temperature: 134 °C Documents included: no Technical drawing…
Additional information: Food; Manhole diameter approx. 410 mm Volumetric volume (L): 2.000 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 4 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume: 170…
Article type: second-hand storage tank Additional information: The agitator drive is missing, there is a loose piece of the platform in the tank. Volumetric volume (L): 5.100 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Top type: conical Shape of tank: cylindrical…
Article type: second-hand storage tank Additional information: The agitator drive is missing Volumetric volume (L): 5.200 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Top type: conical Shape of tank: cylindrical Bottom type: conical Total discharge: yes Fixation points: 3 non adjustable…
Additional information: Pharmacy; 4 stainless steel 304 brackets; total height indicated is estimated Volumetric volume (L): 2.950 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 2,50 Bar Min. pressure (Bar): 0,90 Bar Max. temperature (°C): 138 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no…
Additional information: Chemistry; Attention: type plate only available for one of the two tanks; further small differences in the design of the two tanks (e.g. for the tank with nameplate, the wall thickness of the two bottoms is approx. 6.4 mm) Volumetric volume (L): 2.728 L Pressure in tank: vacuum Min. pressure (Bar): 1 Bar Max. temperature (°C): 100 °C…
Additional information: chemical industry Volumetric volume (L): 3.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Type HE on the bottom: heating/cooling jacket Type HE on the cylinder: heating/cooling jacket Documents included: no Technical drawing included:…
Additional information: Pharmaceutical Chemistry; 2 support brackets made of Fe (contact surface the other way around with cut off steel parts; see photos); further techn. Documents available; manhole cover plated; Metallic discolouration inside Volumetric volume (L): 2.750 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material…
Additional information: Pharmaceutical Chemistry; Manhole DN 350/450 (sight glass in the manhole cover is missing); support ring, Fe; Flanges partly made of Fe Volumetric volume (L): 2.420 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single…
Additional information: Pharmaceutical chemistry; The drawing is a standard drawing; slight deviations are possible; 2 support brackets, Aisi 304; Double jacket made of 1.4541 (Aisi 304) around the lower cylinder area and the lower bottom Volumetric volume (L): 2.355 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200…
Additional information: Pharmaceutical chemistry; Manhole DN 350/450 (manhole cover incomplete); Support ring, Fe; Flanges partially Fe Volumetric volume (L): 2.420 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation:…
Additional information: brewery; 1 pipe inside the tank (see photos); manhole appr. 345 x 440 mm; dents at the insulation jacket Volumetric volume (L): 3.600 L Pressure in tank: pressure Max. pressure (Bar): 2,60 Bar Max. temperature (°C): 20 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total…
