Volym i liter Volym i literAnvänd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
Additional information: Diameter handhole 200 mm; some residues of previous content Volumetric volume (L): 180 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Type HE on the bottom: heating/cooling jacket Type HE on the cylinder: heating/cooling…
Article type: second-hand pressure tank Additional information: The tanks have never been used. Volumetric volume (L): 185 L Pressure in tank: pressure Max. pressure (Bar): 6 Bar Min. pressure (Bar): -1 Bar Max. temperature (°C): 130 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 316L (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank:…
Additional information: Pharmacy; Feet with load cells (see photos) Volumetric volume (L): 198 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume:…
Additional information: Pharmacy; Vessel stands on load cells (4 pcs.); vessel height as per drawing without agitators; anchor agitator with wall scrapers Volumetric volume (L): 200 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 4 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with…
item available on order Article type: brand new transport tank - type VC-SCO Additional information: example picture; Ra=<0.8µm Volumetric volume (L): 200 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2b Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 316L (V4A) Model:…
Additional information: Pharmacy; Diameter of hand hole approx. 175 mm; 1 longitudinal sight glass in the cylinder; 2 screw connections of the upper bottom missing; 1 flat plate inside the tank (probably level indicator, but without scaling) Volumetric volume (L): 200 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat…
item available on order Article type: brand new storage tank - type VC-SLO Additional information: Ra=<0.8µm Volumetric volume (L): 200 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2b Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 316L (V4A) Model: vertical Configuration:…
Additional information: Tank hangs in a former stainless steel tilting frame (currently not tiltable); tank open at the top with a screwed-on, foldable stainless steel protective grille; outlet with plunger (requires on-site modification; plunger does not close tightly) Volumetric volume (L): 200 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 100 °C Configuration: single jacketed with heat-exchanger Heat…
item available on order Article type: brand new mixing tank - type VS-H12S-IL Additional information: Heat exchanger on cylinder and bottom steam, hot water or thermal oil, as well as ice water or glycol; article price without agitator; Volumetric volume (L): 200 L Max. density P (kg/m³): 2.000 Ra inner weld: 0,80 Finish stainless steel: 2B Pressure in tank: ATM…
Additional information: pharmacy; according to a sticker of the former operator max. working pressure 1,1 bar; 1 dent in the insulation jacket; insulation jacket of the lower bottom as well as counterweight of the upper bottom made of Fe; hand lever of the outlet valve is missing Volumetric volume (L): 200 L Pressure in tank: ATM - atmosferic Material wet…
Additional information: Solvents; Manufacturer's description available; No bottom outlet Volumetric volume (L): 204 L Pressure in tank: pressure Max. pressure (Bar): 3 Bar Max. temperature (°C): 50 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: no Documents included: no Technical drawing included: no Registration plate on…
Article type: brand new production tank Volumetric volume (L): 210 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2B Pressure in tank: pressure Design pressure (Bar): 1,90 Bar Max. pressure (Bar): 1,10 Bar Min. pressure (Bar): -0,04 Bar Max. temperature (°C): 150 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 316L (V4A)…
Volym i liter
Använd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
