- Tankar
120 liter tank i Syrafast 316
- 56 000 SEK /st exkl moms
- Additional information: Pharmacy; Mobile stainless steel 304 frame; cover clamping ring missing Volumetric volume (L): 120 L Pressure in tank: pressure Max. pressure (Bar): 1,50 Bar Max. temperature (°C): 130 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 16 L Max…
- Lägg till i varukorg
-
-
-
- Tankar
230 liter tank i Rostfritt 304
- 81 000 SEK /st exkl moms
- Article type: second-hand pressure tank Additional information: we can’t give any guarantees about the heating/cooling jacket Volumetric volume (L): 230 L Pressure in tank: pressure Material wet parts: SS AISI 304L (V2A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Top type: dished Shape of tank: cylindrical Bottom type: strong conical Bottom outlet: yes…
- Lägg till i varukorg
-
-
-
- Tankar
1344 liter tank i Syrafast 316
- 211 000 SEK /st exkl moms
- Additional information: Pharmacy; Vessel was converted at the end of 2012 (nozzle welding and shortening of the feet; TÜV test certificate available; the drawing attached is the original drawing; 1 dent in the insulating jacket Volumetric volume (L): 1.344 L Pressure in tank: vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material…
- Lägg till i varukorg
-
-
-
- Tankar
1229 liter tank i Syrafast 316
- 217 000 SEK /st exkl moms
- Additional information: Pharmacy; Tank was rebuilt in 2011; further technical documents available Volumetric volume (L): 1.229 L Pressure in tank: vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total discharge: yes Volume: 88…
- Lägg till i varukorg
-
-
-
- Tankar
530 liter tank i Syrafast 316
- 167 000 SEK /st exkl moms
- Additional information: Double jacket must be operated without pressure; 2 electric heaters (6 kW) for heating the heating medium in the double jacket; Attention: The vessel is delivered without heating medium (glycerine or thermal oil), which must be filled in on site before commissioning; switch cabinet for the electric heaters available (temperature of the double jacket can be regulated via…
- Lägg till i varukorg
-
-
-
- Tankar
350 liter tank i Rostfritt 304
- 26 000 SEK /st exkl moms
- Additional information: Smaller dents in the insulation jacket (see photos) Volumetric volume (L): 350 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Top type: open Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange…
- Lägg till i varukorg
-
-
-
- Tankar
310 liter tank i Syrafast 316
- 48 000 SEK /st exkl moms
- Additional information: Pharmacy (liquids; not hazardous to health); Test pressure: 1.5 bar; test temperature: 127° C; 1 step on the outside of the vessel; 1 head hole diameter 300 mm in the upper bottom; 2 welded brackets on the inside; small pressure points in the insulation jacket Volumetric volume (L): 310 L Pressure in tank: ATM - atmosferic Max. pressure…
- Lägg till i varukorg
-
-
-
- Tankar
600 liter tank i Syrafast 316
- 69 000 SEK /st exkl moms
- item available on order Article type: brand new storage tank - type K2-SL Volumetric volume (L): 600 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2b Pressure in tank: ATM - atmosferic Design pressure (Bar): 0,05 Bar Max. temperature (°C): 100 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 316L (V4A) Model:…
- Lägg till i varukorg
-
-
-
- Tankar
600 liter tank i Rostfritt 304
- 66 000 SEK /st exkl moms
- item available on order Article type: brand new storage tank - type K2-SL Volumetric volume (L): 600 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2b Pressure in tank: ATM - atmosferic Design pressure (Bar): 0,05 Bar Max. temperature (°C): 100 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 304L (V2A) Model:…
- Lägg till i varukorg
-
-
-
- Tankar
500 liter tank i Syrafast 316
- 183 000 SEK /st exkl moms
- item available on order Article type: brand new mixing tank - type VS-H12S-IL Additional information: Heat exchanger on cylinder and bottom steam, hot water or thermal oil, as well as ice water or glycol; article price without agitator; Volumetric volume (L): 500 L Max. density P (kg/m³): 2.000 Ra inner weld: 0,80 Finish stainless steel: 2B Pressure in tank: ATM…
- Lägg till i varukorg
-
-
-
- Tankar
300 liter tank i Syrafast 316
- 167 000 SEK /st exkl moms
- item available on order Article type: brand new mixing tank - type VS-H12S-IL Additional information: Heat exchanger on cylinder and bottom steam, hot water or thermal oil, as well as ice water or glycol; article price without agitator; Volumetric volume (L): 300 L Max. density P (kg/m³): 2.000 Ra inner weld: 0,80 Finish stainless steel: 2B Pressure in tank: ATM…
- Lägg till i varukorg
-
-
-
- Tankar
730 liter tank i Rostfritt 304
- 189 000 SEK /st exkl moms
- item available on order Article type: brand new pressure tank - type CCT-HIL Additional information: Ra=<0.8µm Volumetric volume (L): 730 L Max. density P (kg/m³): 1.050 Ra inner weld: 0,80 Finish stainless steel: 2b Pressure in tank: pressure Design pressure (Bar): 3,30 Bar Max. temperature (°C): 30 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 304L (V2A)…
- Lägg till i varukorg
-
