Volym i liter Volym i literAnvänd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
Article type: second-hand storage tank Additional information: The casters and some of the closures for the manway are missing. Special flange on the outlet, we can adjust this to a connection of your choice, this costs €474. We can modify the tank for you, contact us without obligation for your quote. Volumetric volume (L): 300 L Ra inner weld: 0,80…
Article type: second-hand storage tank Additional information: The wheels, manhole flange and closures for the manhole are missing, a new lid with closures = €1900; Special flange on the outlet, we can adjust this to a connection of your choice, this costs €474. We can modify the tank for you, contact us without obligation for your quote. Volumetric volume (L):…
Additional information: Biotechnology; Technical documentation in Finnish Volumetric volume (L): 300 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 30…
Additional information: Pharmacy (liquids; not hazardous to health); Test pressure: 1.5 bar; Test temperature: 127 ° C .; 1 step on the outside of the tank; 1 head hole diameter 300 mm in the top bottom; 2 welded brackets inside; small dents in the insulation jacket Volumetric volume (L): 310 L Pressure in tank: pressure Max. pressure (Bar): 1 Bar…
Additional information: Pharmacy; Mobile Frame, AISI 304 (the control cabinet boxes shown in the photos are empty); smaller dents inside the tanks; Upper bottoms, Aisi 304 (hangings and fastening screws of the upper bottoms are missing); pipe end cut flush; Metallic discolouration inside Volumetric volume (L): 313 L Pressure in tank: pressure Max. pressure (Bar): 3 Bar Max. temperature (°C):…
Additional information: chemistry; 3-footed frame, Fe (lacquered; 1 foot shortened); clamp srews, Fe (with corrosion); some residues of previous content Volumetric volume (L): 313 L Pressure in tank: pressure Max. pressure (Bar): 3 Bar Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume:…
Additional information: Cosmetics; Rounded heating coil inside the vessel (see photos); diameter of hand hole approx. 300 mm Volumetric volume (L): 318 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 143 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes…
Additional information: Tank hanging on 3 "feet" in frame or ceiling; Hand hole diameter approx. 300 mm; Outlet fitting is missing; some residues of previous content Volumetric volume (L): 324 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 134 °C Material wet parts: SS AISI 316 (V4A) Model:…
Additional information: Pharmaceutical chemistry; Suspended design on 4 mild steel beams, which were bolted under a working platform; specified total height including these beams (total height of vessel only without beams approx. 1,830 mm); some residues of previous content Volumetric volume (L): 340 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,45 Bar Min. pressure (Bar): 1 Bar…
item available on order Article type: brand new storage tank - type K3-H12S-L Volumetric volume (L): 340 L Max. density P (kg/m³): 1.500 Ra inner weld: 0,80 Finish stainless steel: 2B Pressure in tank: pressure Max. pressure (Bar): 0,49 Bar Min. pressure (Bar): -0,60 Bar Max. temperature (°C): 150 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI…
Additional information: Pharmacy; 1 pump is included in delivery (no guarantee of functionality) Volumetric volume (L): 390 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 4 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no…
Additional information: plastics industry; stronger adhesions inside; working pressure according to drawing (type plate not available); various changes of the connections by the former operator (not shown in the drawing); foot frame, 304 Volumetric volume (L): 396 L Pressure in tank: pressure Max. pressure (Bar): 3 Bar Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger…
Volym i liter
Använd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
