Volym i liter Volym i literAnvänd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
Article type: second-hand pressure tank Volumetric volume (L): 280 L Pressure in tank: pressure Design pressure (Bar): 3,80 Bar Max. pressure (Bar): 2,50 Bar Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Shape of tank: cylindrical Bottom type: dished Total discharge: yes Fixation points: 3 adjustable feet Outer jacket…
Additional information: Pharmacy; Max.permissible temperature in the test certificate: -10 / + 120 ° C; tank drawing in jpeg format and installation drawing available Volumetric volume (L): 280 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,50 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 130 °C Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile…
Additional information: Pharmacy; Air-controlled outlet valve; hand hole diameter 200 mm Volumetric volume (L): 280 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 130 °C Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume: 17 L Max Overpressure: 6 Bar Max…
Additional information: Pharmazie; inkl. Pumpe und UV-Reaktor Volumetric volume (L): 295 L Pressure in tank: pressure Max. pressure (Bar): 0,50 Bar Max. temperature (°C): 100 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume: 9 L Max Overpressure: 3 Bar Max. working temperature:…
Volumetric volume (L): 300 L Pressure in tank: ATM - atmosferic Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Outlet of tank: DN50 DIN 11851 Internal diameter tank: 630 mm Cylinder height: 960 mm Total height of tank:…
Article type: second-hand storage tank Additional information: Some of the closures for the manway are missing. Special flange on the outlet, we can adjust this to a connection of your choice, this costs €474. We can modify the tank for you, contact us without obligation for your quote. Volumetric volume (L): 300 L Ra inner weld: 0,80 Pressure in tank:…
item available on order Article type: brand new transport tank - type VC-SCO Additional information: example picture Volumetric volume (L): 300 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2b Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 316L (V4A) Model: vertical…
Volumetric volume (L): 300 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Outlet of tank: DN50 DIN 11851 Internal diameter tank: 820 mm Cylinder height: 518…
Article type: second-hand storage tank Additional information: The casters and some of the closures for the manway are missing. Special flange on the outlet, we can adjust this to a connection of your choice, this costs €474. We can modify the tank for you, contact us without obligation for your quote. Volumetric volume (L): 300 L Ra inner weld: 0,80…
item available on order Article type: brand new mixing tank - type VC-SLA Additional information: delivered with food certificate; article price without agitator; choice of 2 different types of agitators; see options; (The article can also be purchased without options); Ra=<0.8µm Volumetric volume (L): 300 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2b Pressure…
Volumetric volume (L): 300 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Max Overpressure: 5 Bar Max. working temperature: 80 °C Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Outlet of…
Article type: second-hand storage tank Additional information: The wheels, manhole flange and closures for the manhole are missing, a new lid with closures = €1900; Special flange on the outlet, we can adjust this to a connection of your choice, this costs €474. We can modify the tank for you, contact us without obligation for your quote. Volumetric volume (L):…
Additional information: pharmacy Volumetric volume (L): 300 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 144 °C Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume: 33 L Max Overpressure: 5 Bar Max onderdruk: 1 Bar Max. working temperature: 144 °C…
item available on order Article type: brand new mixing tank - type VS-H12S-IL Additional information: Heat exchanger on cylinder and bottom steam, hot water or thermal oil, as well as ice water or glycol; article price without agitator; Volumetric volume (L): 300 L Max. density P (kg/m³): 2.000 Ra inner weld: 0,80 Finish stainless steel: 2B Pressure in tank: ATM…
Article type: second-hand storage tank Additional information: Some of the closures for the manway are missing. Special flange on the outlet, we can adjust this to a connection of your choice, this costs €474. We can modify the tank for you, contact us without obligation for your quote. Volumetric volume (L): 300 L Ra inner weld: 0,80 Pressure in tank:…
item available on order Article type: brand new mixing tank - type VC-SCA Additional information: delivered with food certificate; article price without agitator; choice of 2 different types of agitators; see options; (The article can also be purchased without options); Ra=<0.8µm Volumetric volume (L): 300 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2b Pressure in…
item available on order Article type: brand new mixing tank - type VC-HILA Additional information: delivered with food certificate; article price without agitator; choice of 2 different types of agitators; see options; (The article can also be purchased without options); Ra=<0.8µm Volumetric volume (L): 300 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2b Pressure…
Additional information: Biotechnology; Technical documentation in Finnish Volumetric volume (L): 300 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 30 L Max Overpressure: 3 Bar Max onderdruk: 1 Bar…
item available on order Article type: brand new storage tank - type VC-SLO Volumetric volume (L): 300 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2b Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 316L (V4A) Model: vertical Configuration: single-skin Heat exchanger:…
item available on order Article type: brand new mixing tank - type VC-HICA Additional information: example picture; delivered with food certificate; article price without agitator; choice of 2 different types of agitators; see options; (The article can also be purchased without options); Ra=<0.8µm Volumetric volume (L): 300 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2b…
Additional information: Powder mixer in the food industry; Manhole diameter approx. 410 mm; Support ring and plate on the outside of the lower bottom made of Fe; Grayish protective coating on the outside Volumetric volume (L): 300 L Pressure in tank: ATM - atmosferic Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no…
item available on order Article type: brand new storage tank - type K2-SL Volumetric volume (L): 300 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2b Pressure in tank: ATM - atmosferic Design pressure (Bar): 0,05 Bar Max. temperature (°C): 100 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 316L (V4A) Model:…
Additional information: colours & coatings; Manhole diameter: approx. 395 mm; ; some residues of previous content Volumetric volume (L): 300 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the…
Additional information: Pharmacy (liquids; not hazardous to health); Test pressure: 1.5 bar; Test temperature: 127 ° C .; 1 step on the outside of the tank; 1 head hole diameter 300 mm in the top bottom; 2 welded brackets inside; small dents in the insulation jacket Volumetric volume (L): 310 L Pressure in tank: pressure Max. pressure (Bar): 1 Bar…
Volym i liter
Använd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
