Volym i liter Volym i literAnvänd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
Additional information: Cosmetics; Rounded heating coil inside the vessel (see photos); diameter of hand hole approx. 300 mm Volumetric volume (L): 318 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 143 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes…
Additional information: chemistry; tanks with differences in design (e. g. stirring elements and the number of windings of the heating coil; see pictures); some residues of previous content Volumetric volume (L): 500 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank:…
Volumetric volume (L): 680 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 2 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 134 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: no Volume: 55 L Max Overpressure: 3 Bar Max onderdruk: 1…
Additional information: Smaller dents in the insulation jacket; 2 hand holes with a diameter of approx. 175 mm each and 1 elongated sheet metal cutout in the lid (see photos); some residues of previous content Volumetric volume (L): 850 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no…
item available on order Article type: brand new transport tank - type VC-SCO Additional information: example picture Volumetric volume (L): 1.000 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger:…
item available on order Article type: brand new transport tank Additional information: GGVSEB / GGVSea / ADR / RID / IMDG-Code Volumetric volume (L): 1.000 L Max. density P (kg/m³): 2.100 Pressure in tank: pressure Max. pressure (Bar): 0,20 Bar Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top…
Additional information: Chemistry; 4 feet, Aisi 304, screwed to transport frame, Fe (galvanized); Manhole diameter approx. 380 mm (manhole cover screws partially incomplete; slight differences in the design of the containers are possible; some residues of previous content; traces of usage Volumetric volume (L): 1.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model:…
Additional information: Chemistry; 4 feet, Aisi 304, screwed to transport frame, Fe (galvanized); Manhole diameter approx. 380 mm (manhole cover screws partially incomplete; slight differences in the design of the containers are possible; some residues of previous content; traces of usage Volumetric volume (L): 1.030 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model:…
Volumetric volume (L): 1.150 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Fixation point(s): plastic Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Outlet of…
