Volym i liter Volym i literAnvänd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
Additional information: Pharmaceutical chemistry; Double jacket made of stainless steel 304 around the lower cylinder area and the lower base; 3 stainless steel claws; parts of the insulating collar were cut off during disassembly; bump at the insulation jacket Volumetric volume (L): 2.330 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar…
Additional information: Pharmaceutical chemistry; The drawing is a standard drawing; slight deviations are possible; 2 support brackets, Aisi 304; Double jacket made of 1.4541 (Aisi 304) around the lower cylinder area and the lower bottom Volumetric volume (L): 2.355 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200…
Additional information: Pharmaceutical chemistry; Manhole DN 350/450 (manhole cover incomplete); Support ring, Fe; Flanges partially Fe Volumetric volume (L): 2.420 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation:…
Additional information: Pharmaceutical Chemistry; Manhole DN 350/450 (sight glass in the manhole cover is missing); support ring, Fe; Flanges partly made of Fe Volumetric volume (L): 2.420 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single…
Additional information: Pharmaceutical Chemistry; 2 support brackets made of Fe (contact surface the other way around with cut off steel parts; see photos); further techn. Documents available; manhole cover plated; Metallic discolouration inside Volumetric volume (L): 2.750 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material…
Additional information: Pharmaceutical chemistry; 3 support brackets, Aisi 304; double jacket for heating/cooling around the lower cylinder area and the lower bottom (double jacket was added later and is not shown in the vessel drawing); slight differences in the design of the two vessels, e.g. differences in the manhole covers and the outlets (1 x outlet diameter approx. 53 mm,…
Additional information: Chemistry; 4 support brackets made of Fe; 1 vessel with insulation (insulation jacket Fe, lacquered; diameter outside approx. 1780 mm); some residues of previous content; Metallic discolouration inside Volumetric volume (L): 3.685 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS…
Additional information: Pharmaceutical Chemistry; Stand frame, Aisi 304; wall thickness of the lowest cylinder segment approx. 6 mm; 2 of these tanks are from the manufacturer Metkon, but almost identical; Extensive documentation available; tank by now already dismantled and warehoused horizontally; two tanks with insulation, which is quite dented and should be replaced if required; special price applies only to…
Additional information: Adhesive production; Manhole diameter upper bottom: approx. 700 mm; Manhole diameter cylinder: approx. 500 mm Volumetric volume (L): 29.000 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 0,60 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 100 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes…
Article type: second-hand storage tank Additional information: Suction tube instead of a total drain, the previous product was ammonia Volumetric volume (L): 42.610 L Pressure in tank: pressure Max. pressure (Bar): 2,60 Bar Material wet parts: SS AISI 304 (V2A) Model: horizontal Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: dished Shape of tank: cylindrical Wall…
Additional information: Rapeseed oil; Manhole cylinder NW 600; smaller sheet metal cutouts in the insulation jacket; bump at the insulation jacket; manhole cover plated Volumetric volume (L): 60.000 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 1,50 Bar Min. pressure (Bar): 0,20 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration:…
