Additional information: Biotech; 4 feet bolted to height-adjustable stainless steel weighing pallet; hand hole DN 200; an identical second vessel can be offered on request Volumetric volume (L): 1.600 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 160 °C Material wet parts: SS AISI 316 (V4A) Model: vertical…
Volumetric volume (L): 1.150 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Fixation point(s): plastic Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Outlet of…
Additional information: Manhole diameter: approx. 420 x 320 mm Volumetric volume (L): 2.100 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Max Overpressure: 6 Bar Documents included: no Technical drawing included: no Registration plate on the…
Article type: second-hand mixing tank Additional information: we can’t give any guarantees about the agitator Volumetric volume (L): 3.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: no Mobile tank: no Top type: conical Shape of tank: cylindrical Bottom type: conical Total discharge: yes Fixation points:…
Volumetric volume (L): 1.150 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Fixation point(s): plastic Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Outlet of…
Volumetric volume (L): 1.150 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Top type: open Total discharge: yes Volume: 4 L Max Overpressure: 5 Bar Max. working temperature: 80 °C Fixation point(s): plastic Documents…
Additional information: pharmacy Volumetric volume (L): 1.100 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 1 Bar Min. pressure (Bar): 0,50 Bar Max. temperature (°C): 50 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate…
Additional information: Full set of pharma-compliant technical documentation included in delivery; tank was manufactured for a global pharmaceutical company but was never put into operation; Hand hole with sight glass diameter: 150mm; incl. Südmo single-seat valve SVP (outlet) Volumetric volume (L): 1.700 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max.…
Volumetric volume (L): 1.169 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 100 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Max Overpressure: 2,50 Bar Max. working temperature: 140 °C Documents included: no Technical drawing included: no Registration plate on the…
Additional information: Chemistry; Partly small dents Volumetric volume (L): 3.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Position of manway: headside…
Additional information: Cosmetics; Tank 1: smaller dents in the lower bottom, manhole diameter approx. 430 mm (loose manhole cover), total height lower (approx. 1,450 mm); Tank 2: manhole diameter approx. 500 mm; tank with stronger dents; see photos Volumetric volume (L): 1.200 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin…
Volumetric volume (L): 1.150 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 4 L Max Overpressure: 5 Bar Max. working temperature: 80 °C Heat exchanger: RVS 304 Fixation point(s): plastic…
