Volym i liter Volym i literAnvänd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
Additional information: Winery; Manhole approx. 320 x 420 mm; Tanks marbled on one side on the outside; the foot lengths on the individual tanks are slightly different (usually 1 foot is shorter than the other two feet; the feet would have to be modified or relined accordingly before re-installation); 1 tank with a smaller dent in the upper cylinder area…
Additional information: Food industry; Smaller dents in the insulation jacket; some residues of previous content Volumetric volume (L): 5.000 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 100 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume: 100 L Max Overpressure:…
Article type: second-hand pressure tank Additional information: PED file on demand; the tank has never been used Volumetric volume (L): 5.000 L Max. density P (kg/m³): 1.800 Pressure in tank: pressure Max. pressure (Bar): 6 Bar Min. pressure (Bar): -1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316L (V4A) Model: vertical Configuration: insulated Heat exchanger: no…
Additional information: Detergents; Manhole cylinder appr. 310 x 440 mm; Height-adjustable screws of the feet are no longer available; screwed-on plastic fitting on the outlet (see photos); Device for level indicator outside (no longer complete); some residues of previous content Volumetric volume (L): 5.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical…
Additional information: Frame, Aisi 304 (currently 4 wooden blocks are screwed under; see photos); Manhole approx. 345 x 440 mm; some residues of previous content Volumetric volume (L): 5.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included:…
Additional information: Fruit juice; Manhole approx. 310 x 410 mm; small dents in the cylinder; some residues of previous content Volumetric volume (L): 5.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no…
Additional information: chemistry; 2 tanks (6169-3+5) with broken intermediate flange at the gear; some residues of previous content Volumetric volume (L): 5.000 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 60 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume:…
Volym i liter
Använd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
