Additional information: Chemistry; Half-coils cylinder only in the lower cylinder area; some residues of previous content Volumetric volume (L): 4.500 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Max Overpressure: 6 Bar Type HE on the…
Additional information: Chemistry; Manhole diameter approx. 410 mm; 1 baffle inside over the outlet; insulation around the cylinder; some residues of previous content Volumetric volume (L): 850 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total discharge: yes Documents included: no Technical…
Additional information: Chemistry; Support ring made of Aisi 304; 1 tank with 2 smaller dents in the lower bottom; in the case of one tank, the outlet is pressed slightly into the lower bottom; 1 tank with flange-mounted outlet fitting (if used, the total height would increase by approx. 320 mm); some residues of previous content Volumetric volume (L): 1.200…
Additional information: Chemistry; Insulation around the upper bottom; support ring made of Fe; drawing not available; diameter manhole 470 mm Volumetric volume (L): 8.651 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat…
Additional information: Brine tank (water / salt solution) in a chemical plant; Manhole cylinder DN 600; double outlet DN 50; some residues of previous content Volumetric volume (L): 10.800 L Pressure in tank: pressure Max. pressure (Bar): 3,20 Bar Max. temperature (°C): 100 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no…
Volumetric volume (L): 550 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 3 L Max Overpressure: 5 Bar Max. working temperature: 80 °C Fixation point(s): plastic Documents included: no Technical…
Volumetric volume (L): 550 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Fixation point(s): plastic Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Outlet of…
Additional information: seal manufacturing; insulation jacket with dents and metal cutoffs; 1 bent connection in the upper bottom; slight metallic discolourations inside; some residues of previous content Volumetric volume (L): 10.000 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation:…
Additional information: wine storage; Slight differences in design possible (e.g. partly 3 feet, partly 4 feet); manhole approx. 340 x 440 mm Volumetric volume (L): 11.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing…
Additional information: steel alloys; cone height approx. 1200 mm; hand hole approx. 220 x 315 mm; hand hole collar and hand hole cover made of Fe; the hand hole cover is missing for 1 tank; fastenings of the hand hole covers of the other tanks are incomplete; some residues of previous content Volumetric volume (L): 265 L Pressure in tank:…
Additional information: food industry; tank cover made of 1.4301 (Aisi 304); some residues of previous content Volumetric volume (L): 700 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the…
Additional information: food industry; adhesions and metallic discolourations inside the tank; tank cover made of 1.4301 (aisi 304); motor-/gear is missing Volumetric volume (L): 1.100 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 134 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge:…
Additional information: Cip-tank in an brewery; pipelines inside the tank (see photos); diameter manhole approx. 400 mm Volumetric volume (L): 6.100 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on…
Additional information: pharmacy; Pneumatic butterfly valve; welded pipeline inside the tank (see photos); cone height approx. 530 mm; minor differences in the design of the tanks possible Volumetric volume (L): 1.235 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 0,50 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 100 °C Material wet parts: SS AISI 304 (V2A)…
Volumetric volume (L): 1.150 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: open Total discharge: yes Fixation point(s): plastic Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Outlet of tank: DN50…
Volumetric volume (L): 550 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: open Total discharge: yes Fixation point(s): plastic Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator:…
Volumetric volume (L): 540 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Fixation point(s): plastic Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Position of…
Additional information: yeast tank in a brewery; cone height appr. 1.300 mm Volumetric volume (L): 13.700 L Pressure in tank: pressure Max. pressure (Bar): 1 Bar Max. temperature (°C): 20 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 40 L Max…
Additional information: brewery; 1 pipe inside the tank (see photos); manhole appr. 345 x 440 mm; dents at the insulation jacket Volumetric volume (L): 3.600 L Pressure in tank: pressure Max. pressure (Bar): 2,60 Bar Max. temperature (°C): 20 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total…
Additional information: condensate tank in a brewery; manhole appr. 340 x 420 mm; some residues of previous content; dents at the insulation jacket; pipe end cut flush Volumetric volume (L): 650 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 180 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile…
Additional information: spirits; manhole appr. 350 x 450 mm Volumetric volume (L): 6.800 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Position…
Additional information: Aromafabrik Volumetric volume (L): 990 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Outlet of tank: available Agitator: yes Number…
Additional information: food colours; cylinder can only be heated in the lower area; 1 distillation column / heat exchanger made of V2A are included (see photos; not taken into account in the total height); some residues of previous content; bump at the insulation jacket; manhole cover plated Volumetric volume (L): 1.750 L Pressure in tank: vacuum Min. pressure (Bar): 1…
Additional information: pharmacy; metallic discolourations inside Volumetric volume (L): 650 L Pressure in tank: pressure Max. pressure (Bar): 1,50 Bar Max. temperature (°C): 170 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Max Overpressure: 8 Bar Max. working temperature: 170 °C Type HE…
