Article type: second-hand transport tank Additional information: The tanks have some dents; look closely at the photos; used for various egg products. Not all tanks have nameplates, bayonet manhole closure. Volumetric volume (L): 800 L Pressure in tank: pressure Design pressure (Bar): 2,86 Bar Max. pressure (Bar): 2 Bar Min. pressure (Bar): -0,15 Bar Max. temperature (°C): 130 °C Min.…
Additional information: Brewery Volumetric volume (L): 3.000 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Max. temperature (°C): 134 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Max Overpressure: 2 Bar Max. working temperature: 134 °C Documents included: no Technical drawing…
Additional information: Trolley not available for all tanks; 1 tank with a smaller dent; the details of total length, width and height refer to tank including trolley (total height without trolley 850 mm) Volumetric volume (L): 80 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model:…
Additional information: Biochemistry; 1 manhole diameter 400 mm in the front base; some residues of previous content; manhole cover plated Volumetric volume (L): 715 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: horizontal Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge:…
Additional information: Biochemistry; Diameter of hand hole approx. 260 mm (hand hole lid plated); adhesions and metallic discoloration inside the vessel Volumetric volume (L): 270 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no…
Additional information: Pharmacy; Manhole diameter approx. 600 mm (1 opening diameter 165 mm in manhole cover); 2 bearing saddles made of Fe (painted); outlet with flanged fitting; some residues of previous content; manhole cover plated Volumetric volume (L): 11.650 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 2 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200…
Additional information: Food; DN 100 hand hole in the upper bottom (in some cases the union nut is missing); small dents possible in some places Volumetric volume (L): 1.000 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Max. temperature (°C): 130 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no…
Additional information: Pharmacy; 1 screw connection of the manhole cover damaged Volumetric volume (L): 1.000 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Max. temperature (°C): 120 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume: 97 L Max Overpressure: 2…
Additional information: Pharmacy Volumetric volume (L): 500 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Position of manway: headside…
Additional information: Pharmacy; scratches inside Volumetric volume (L): 568 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 2 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 134 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 108 L Max…
item available on order Article type: brand new transport tank Volumetric volume (L): 1.000 L Max. density P (kg/m³): 1.500 Ra inner weld: 0,80 Pressure in tank: pressure Design pressure (Bar): 3,40 Bar Max. pressure (Bar): 2 Bar Min. pressure (Bar): -0,15 Bar Max. temperature (°C): 130 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 304 (V2A)…
Additional information: Brewery; Manhole diamter approx. 300 x 395 mm (manhole cover missing); some residues of previous content Volumetric volume (L): 3.000 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included:…
