Volym i liter Volym i literAnvänd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
Additional information: Biochemistry; Several pipes inside the tank; loose flanges made of Fe (galvanized) Volumetric volume (L): 500 L Pressure in tank: ATM - atmosferic Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Outlet of tank: 55 Internal…
Additional information: Dairy; Outlet with bead and 2 connections, inner diameter approx. 60 mm; 3 plastic base plates; slight metallic discoloration inside Volumetric volume (L): 500 L Pressure in tank: ATM - atmosferic Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange…
Article type: second-hand transport tank Volumetric volume (L): 500 L Pressure in tank: pressure Max. pressure (Bar): 0,25 Bar Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: conical Shape of tank: square Bottom type: flat sloping Total discharge: yes Fixation points: 4 non adjustable feet Suitable for…
Additional information: Hand hole diameter 200 mm; Foot frame, Aisi 304 with upper ring made of Fe; other external parts made of Fe (e.g. heating connections; el clamp screws of the upper bottom); double jacket by approx. 600 mm of the cylinder height; 1 small dent in the upper bottom; some residues of previous content Volumetric volume (L): 500 L…
Additional information: Brewery; Tanks loose on frames, Aisi 304 (different versions of the frames, some screwed together; see photos); 1 hand hole each approx. 190 x 240 mm in the front bottom (plastic hand hole cover) Volumetric volume (L): 500 L Pressure in tank: pressure Max. pressure (Bar): 3 Bar Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no…
Additional information: Full set of pharma-compliant technical documentation included in delivery; tank was manufactured for a global pharmaceutical company but was never put into operation; hand hole with sight glass diameter: 285mm Volumetric volume (L): 500 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Configuration: insulated…
Additional information: Pharmacy Volumetric volume (L): 500 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Outlet of tank: DN32 DIN 11851 Internal diameter tank: 790 mm Total height…
Additional information: Brewery; Tanks loose on frames, Aisi 304 (different versions of the frames, some screwed together; see photos); 1 hand hole each approx. 190 x 240 mm in the front bottom (plastic hand hole cover) Volumetric volume (L): 500 L Pressure in tank: pressure Max. pressure (Bar): 3 Bar Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no…
Additional information: Pharmacy Volumetric volume (L): 500 L Pressure in tank: ATM - atmosferic Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Outlet of tank: 28 Internal diameter tank: 790 mm Cylinder height: 1.100 mm Total height of…
Article type: second-hand storage tank Additional information: Immersion resistance DIRAC 1000W - 120°C - 230/400V; Sight glass with lighting. The tank has never been used. Volumetric volume (L): 500 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: yes Insulation: no Mobile tank: no Top type: dished Shape of…
Additional information: Cosmetics; 2 semicircular openings in the upper bottom (1 x stainless steel 304 cover; 1 x plastic cover); some residues of previous content Volumetric volume (L): 500 L Pressure in tank: ATM - atmosferic Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Type HE on the bottom: half pipe welded onto…
Additional information: Vessel currently bolted to an aluminum frame Volumetric volume (L): 507 L Pressure in tank: pressure Max. pressure (Bar): 6,60 Bar Max. temperature (°C): 180 °C Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume: 2 L Max Overpressure: 6 Bar Max. working temperature: 180 °C Documents included: no Technical drawing…
Additional information: Outlet DN 60 DIN 11851; reinforcement ribs inside under the upper bottom (removable); 2 fork pockets on the outside of the lower bottom Volumetric volume (L): 530 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 95 °C Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: no Max Overpressure: 2…
Additional information: Pharmacy; Original drawing available; tank was rebuilt in 1997 (e.g. changing the feet or connections); Evidence of the subsequent pressure test available; Conversion drawing only available as a fax; 1 dip tube inside the tank; some residues of previous content Volumetric volume (L): 530 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure…
Additional information: Biochemistry; Handhole DN 200; some residues of previous content Volumetric volume (L): 530 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 100 °C Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on…
Additional information: Full set of pharma-compliant technical documentation included in delivery; tank was manufactured for a global pharmaceutical company but was never put into operation; hand hole with sight glass diameter: 100mm; incl. Südmo single-seat valve SVP (outlet) Volumetric volume (L): 532 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max.…
Additional information: plastics industry; a number of connections were changed by the former operator; 1 overflow pipe inside; mounting of the manhole cover incomplete; 1 smaller dent inside the tank; some residues of previous content; dents at the insulation jacket Volumetric volume (L): 540 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1…
Article type: second-hand storage tank Additional information: the tanks have never been used Volumetric volume (L): 540 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: dished Shape of tank: cylindrical Bottom type: flat sloping Total discharge: yes Fixation points: 4…
Volumetric volume (L): 540 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Fixation point(s): plastic Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Position of…
Volumetric volume (L): 550 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Outlet of tank: DN50 DIN 11851 Internal diameter tank: 820 mm Cylinder height: 1.034…
Volumetric volume (L): 550 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Outlet of tank: DN50 DIN 11851 Agitator: yes Number of revolutions: 0-275 Power: 0,75…
Additional information: Wine storage; Manhole diameter approx. 410 mm; Container partially with dents Volumetric volume (L): 550 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange…
Additional information: Aromafabrik Volumetric volume (L): 550 L Pressure in tank: ATM - atmosferic Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Outlet of tank: available Agitator: yes Number of revolutions: 50 - 300 Power: 1 Internal diameter…
Volumetric volume (L): 550 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 3 L Max Overpressure: 5 Bar Max. working temperature: 80 °C Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator:…
Volym i liter
Använd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
