Article type: second-hand pressure tank Additional information: Top lid is missing, a new lid = 650 €. There are two connections provided with 2 inch internal thread for mounting 2 immersion resistors with an insertion length of 500mm, the immersion resistors themselves are not included. Volumetric volume (L): 250 L Pressure in tank: pressure Design pressure (Bar): 5,20 Bar Max.…
Additional information: Pharmacy Volumetric volume (L): 250 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 100 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume: 90 L Max Overpressure: 0,50 Bar…
item available on order Article type: brand new pressure tank - type CCT-ES-HL Volumetric volume (L): 260 L Max. density P (kg/m³): 1.400 Finish stainless steel: pickled Pressure in tank: pressure Max. pressure (Bar): 2 Bar Max. temperature (°C): 130 °C Material wet parts: SS AISI 304L (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no…
Additional information: steel alloys; cone height approx. 1200 mm; hand hole approx. 220 x 315 mm; hand hole collar and hand hole cover made of Fe; the hand hole cover is missing for 1 tank; fastenings of the hand hole covers of the other tanks are incomplete; some residues of previous content Volumetric volume (L): 265 L Pressure in tank:…
Additional information: Pharmacy; Slight metallic discoloration inside the vessel Volumetric volume (L): 270 L Pressure in tank: ATM - atmosferic Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Outlet of tank: available Agitator: yes Number of revolutions: 77…
Article type: second-hand pressure tank Volumetric volume (L): 280 L Pressure in tank: pressure Design pressure (Bar): 3,80 Bar Max. pressure (Bar): 2,50 Bar Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Shape of tank: cylindrical Bottom type: dished Total discharge: yes Fixation points: 3 adjustable feet Outer jacket…
Additional information: colours & coatings; Manhole diameter: approx. 395 mm; ; some residues of previous content Volumetric volume (L): 300 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the…
Volumetric volume (L): 300 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: open Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Outlet of tank: DN50 DIN 11851 Internal…
Volumetric volume (L): 300 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Top type: open Total discharge: yes Fixation point(s): plastic Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator:…
Volumetric volume (L): 300 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Top type: open Total discharge: yes Max Overpressure: 5 Bar Max. working temperature: 80 °C Heat exchanger: RVS 304 Fixation point(s): plastic…
Article type: second-hand storage tank Additional information: Some of the closures for the manway are missing. Special flange on the outlet, we can adjust this to a connection of your choice, this costs €474. We can modify the tank for you, contact us without obligation for your quote. Volumetric volume (L): 300 L Ra inner weld: 0,80 Pressure in tank:…
Additional information: pharmacy Volumetric volume (L): 300 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 144 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge: yes Volume: 33 L Max Overpressure: 5 Bar…
