Volym i liter Volym i literAnvänd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
Additional information: Biochemistry; some residues of previous content Volumetric volume (L): 400 L Pressure in tank: ATM - atmosferic Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no Flange for agitator: no Outlet of tank: flange DN50 Internal diameter tank: 990 mm Cylinder…
Additional information: Cosmetics; 4-legged frame made of stainless steel 304; the manhole of one container is slightly pressed into the upper bottom (this container also has a slightly stronger dents in the upper bottom; see photos); traces of usage Volumetric volume (L): 800 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration:…
Additional information: pharmacy; Filling pipe inside the tank (see pictures); GEMÜ diaphragm valve at the outlet Volumetric volume (L): 930 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 130 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes…
Additional information: pharmacy; 1 vessel with extensive documentation (the second vessel only with test certificates and copy of the certificate of conformity); one vessel with dent in the insulating jacket (see pictures); filling pipe inside the vessel (see pictures); GEMÜ diaphragm valve at the outlet Volumetric volume (L): 930 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3…
Additional information: Aromafabrik Volumetric volume (L): 990 L Pressure in tank: ATM - atmosferic Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Outlet of tank: available Agitator: yes Number of revolutions: 50 - 300 Power: 1 Internal diameter…
Additional information: Food; 2 longitudinal sight glasses in the cylinder; outlet fitting (disk tap) incomplete Volumetric volume (L): 1.000 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank:…
Additional information: Dairy; Diameter manhole approx. 420 mm; Insulation around the cylinder (small dents in the insulation jacket) Volumetric volume (L): 1.000 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 90 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total discharge: yes Documents included: no Technical…
Additional information: Food industry; Tanks are slightly out of round due to their design; tanks with small (sometimes slightly larger) dents; some of the tank feet are pressed into the lower bottom; tank lids are made of plastic (2 containers are missing lids; one lid has holes in the lid; see photos) Volumetric volume (L): 1.000 L Pressure in tank:…
Additional information: Biochemistry; Welded stainless steel ring around the outside of the vessel (protrudes approx. 100 mm from the outer diameter (insulation)); some residues of previous content Volumetric volume (L): 1.085 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 95 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation:…
Additional information: Frame, Fe; Tank open at the top with a loose lid segment (see photos) Volumetric volume (L): 1.100 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the…
Additional information: food industry; adhesions and metallic discolourations inside the tank; tank cover made of 1.4301 (aisi 304); motor-/gear is missing Volumetric volume (L): 1.100 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 134 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated with heat-exchanger Heat exchanger: yes Insulation: yes Mobile tank: no Total discharge:…
Additional information: Beverage industry; Diameter manhole appr. 380 mm; some residues of previous content Volumetric volume (L): 1.200 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: no…
Volym i liter
Använd draglisten för det volymspann ni önskar se. Klicka sen i t.ex. (material, omrörare, isolering etc.) för att slutligen klicka på FILTRERA, då visas endast de tankar som finns inom de krav ni angett.
