Additional information: Food Volumetric volume (L): 1.200 L Pressure in tank: ATM - atmosferic Max. temperature (°C): 80 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Position of…
Additional information: 2 different dome cover variants: Milk pipe screw connection (125mm handhole cover) or opening by bayonet punch (400mm manhole) (drawing available) Special tools are required to open the hand and manholes. On request, we will be happy to put you in touch with the relevant manufacturers or assist you with procurement. Volumetric volume (L): 930 L Pressure in…
Additional information: Food; DN 100 hand hole in the upper bottom (in some cases the union nut is missing); small dents possible in some places Volumetric volume (L): 1.000 L Pressure in tank: pressure Max. pressure (Bar): 2 Bar Max. temperature (°C): 130 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no…
Additional information: Manhole diameter: approx. 420 x 320 mm Volumetric volume (L): 1.050 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Max Overpressure: 6 Bar Documents included: no Technical drawing included: no Registration plate on the…
Additional information: Pharmacy; Technical documentation (also for the agitator) available for one of the two vessels Volumetric volume (L): 956 L Pressure in tank: vacuum Min. pressure (Bar): 0,50 Bar Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single jacketed with heat-exchanger Heat exchanger: yes Insulation: no Mobile tank: no Total discharge: yes Volume: 83 L Max Overpressure:…
Additional information: Pharmacy; Various technical documents available; the previous operator had the vessels hanging in a ring with load cells that was embedded in the ground (1 ring of each is included in the delivery; see photos) Volumetric volume (L): 1.350 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature…
Additional information: Pharmacy; Different manufacturers, therefore minor differences in the design (e.g. manhole cover); different outlet valves (on the black rotary valves (see photos) outlet diameter approx. 55 mm); drawing for Eurocont available; traces of usage Volumetric volume (L): 1.000 L Pressure in tank: ATM - atmosferic Max. pressure (Bar): 0,65 Bar Min. pressure (Bar): 0,15 Bar Material wet parts:…
Additional information: some residues of previous content; traces of usage Volumetric volume (L): 800 L Pressure in tank: pressure Max. pressure (Bar): 1 Bar Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange…
Additional information: food industry; minor dents and slight adhesions possible; Manhole is fastened with a clamping ring; various connection designs in the upper bottom; some residues of previous content; traces of usage Volumetric volume (L): 800 L Pressure in tank: pressure Max. pressure (Bar): 1 Bar Max. temperature (°C): 120 °C Material wet parts: SS AISI 304 (V2A) Model: vertical…
Additional information: Tank was manufactured for a global pharmaceutical company but was never put into operation; hand hole with sight glass diameter: 285mm; incl. Südmo single-seat valve SVP (outlet) Volumetric volume (L): 1.000 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI…
Additional information: Tank was manufactured for a global pharmaceutical company but was never put into operation; hand hole with sight glass diameter: 285mm; incl. Südmo single-seat valve SVP (outlet) Volumetric volume (L): 1.000 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 6 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI…
Additional information: Pharmacy; The previous operator had the vessels hanging in a ring with load cells that was embedded in the ground (1 ring of each is included in the delivery; see photos); Outer diameter in the ring approx. 1,540 mm; insulating jacket made of material 1.0425 Volumetric volume (L): 885 L Pressure in tank: pressure and vacuum Max. pressure…
