- Tankar
5650 liter tank i Syrafast 316
- 211 000 SEK /st exkl moms
- Additional information: Water for injections in pharmacy; Manhole DN 500; feet were split by the previous operator so that the tank could be installed in a lower room Volumetric volume (L): 5.650 L Pressure in tank: vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 144 °C Material wet parts: SS AISI 316 (V4A) Model:…
- Lägg till i varukorg
-
-
-
- Tankar
1830 liter tank i Rostfritt 304
- 73 000 SEK /st exkl moms
- Additional information: Pharmazeutische Chemie; 1 manhole diameter 500 mm in the front base; minor dents in the iso jacket; manhole cover plated Volumetric volume (L): 1.830 L Pressure in tank: vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 304 (V2A) Model: horizontal Configuration: insulated Heat exchanger: no…
- Lägg till i varukorg
-
-
-
- Tankar
2420 liter tank i Syrafast 316
- 230 000 SEK /st exkl moms
- Additional information: Pharmaceutical Chemistry; Manhole DN 350/450 (sight glass in manhole cover missing); support ring made of Fe; flanges partly made of Fe Volumetric volume (L): 2.420 L Pressure in tank: vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger:…
- Lägg till i varukorg
-
-
-
- Tankar
500 liter tank i Syrafast 316
- 31 000 SEK /st exkl moms
- Additional information: Pharmaceutical Chemistry; 4 stainless steel claws; 1 manhole diameter 400 mm in the front base; manhole cover plated Volumetric volume (L): 500 L Pressure in tank: vacuum Max. pressure (Bar): 2 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no…
- Lägg till i varukorg
-
-
-
- Tankar
30395 liter tank i Rostfritt 304
- 369 000 SEK /st exkl moms
- Additional information: Dairy; Double jacket with trickle ring - only suitable for unpressurized temperature control; dents in the double jacket; small cracks in the double jacket cladding; some of the connections have been wiped off; 2 dome screws on the feet are missing; pipe end cut flush Volumetric volume (L): 30.395 L Pressure in tank: vacuum Max. pressure (Bar): 3,50…
- Lägg till i varukorg
-
-
-
- Tankar
1969 liter tank i Syrafast 316
- 118 000 SEK /st exkl moms
- Additional information: Pharmaceutical chemistry; 2 stainless steel 304 claws (contact surface the other way round; see photos); some residues of previous content Volumetric volume (L): 1.969 L Pressure in tank: vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no…
- Lägg till i varukorg
-
-
-
- Tankar
2355 liter tank i Syrafast 316
- 94 000 SEK /st exkl moms
- Additional information: Pharmaceutical chemistry; The drawing is a standard drawing; slight deviations are possible; 2 claws made of stainless steel 304; double jacket made of 1.4541 (stainless steel 304) around the lower cylinder area and the lower base Volumetric volume (L): 2.355 L Pressure in tank: vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C):…
- Lägg till i varukorg
-
-
-
- Tankar
729 liter tank i Syrafast 316
- 177 000 SEK /st exkl moms
- Additional information: Tank is currently on a pedestal; should this be used for installation, the total height would increase to approx. 2,600 mm Volumetric volume (L): 729 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 150 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated…
- Lägg till i varukorg
-
-
-
- Tankar
1000 liter tank i Syrafast 316
- 357 000 SEK /st exkl moms
- Additional information: Pharmacy Volumetric volume (L): 1.000 L Pressure in tank: vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total discharge: yes Volume: 5 L Max Overpressure: 6 Bar Max. working temperature: 135…
- Lägg till i varukorg
-
-
-
- Tankar
1200 liter tank i Syrafast 316
- 79 000 SEK /st exkl moms
- Additional information: Pharmacy; DN 500 manhole; parts of the blind screw connections possibly present Volumetric volume (L): 1.200 L Pressure in tank: vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes…
- Lägg till i varukorg
-
-
-
- Tankar
5050 liter tank i Syrafast 316
- 171 000 SEK /st exkl moms
- Additional information: Pharmacy; Manhole DN 600; parts of the blind screw connections possibly present Volumetric volume (L): 5.050 L Pressure in tank: vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes…
- Lägg till i varukorg
-
-
-
- Tankar
6000 liter tank i Syrafast 316
- 196 000 SEK /st exkl moms
- Additional information: Pharmacy; Manhole DN 600; parts of the blind screw connections possibly present Volumetric volume (L): 6.000 L Pressure in tank: vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes…
- Lägg till i varukorg
-
