- Tankar
15600 liter tank i Rostfritt 304
- 150 000 SEK /st exkl moms
- Additional information: Pet food; Diameter manhole approx. 510 mm; 1 x outlet flange diameter pipe inside 80 mm, 1 x threaded outlet diameter pipe inside approx. 150 mm; 1 lateral agitator was welded into the lower cylinder area by the previous operator; the heating coil may have been damaged in the process; insulation was screwed over the heating connections of…
- Lägg till i varukorg
-
-
-
- Tankar
1000 liter tank i Syrafast 316
- 356 000 SEK /st exkl moms
- Additional information: Pharmacy Volumetric volume (L): 1.000 L Pressure in tank: vacuum Max. pressure (Bar): 3 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 135 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no Total discharge: yes Volume: 5 L Max Overpressure: 6 Bar Max. working temperature: 135…
- Lägg till i varukorg
-
-
-
- Tankar
1345 liter tank i Syrafast 316
- 87 000 SEK /st exkl moms
- Additional information: Pharmaceutical chemistry; 2 claws made of stainless steel 304 (contact surface the other way round; see photos); flanges partly made of Fe; further technical documents available; bump at the insulation jacket Volumetric volume (L): 1.345 L Pressure in tank: vacuum Max. pressure (Bar): 3,20 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 200 °C Material wet parts:…
- Lägg till i varukorg
-
-
-
- Tankar
1235 liter tank i Rostfritt 304
- 49 000 SEK /st exkl moms
- Additional information: pharmacy; Pneumatic butterfly valve; welded pipeline inside the tank (see photos); cone height approx. 530 mm; minor differences in the design of the tanks possible Volumetric volume (L): 1.235 L Pressure in tank: pressure and vacuum Max. pressure (Bar): 0,50 Bar Min. pressure (Bar): 1 Bar Max. temperature (°C): 100 °C Material wet parts: SS AISI 304 (V2A)…
- Lägg till i varukorg
-
-
-
- Tankar
10000 liter tank i Rostfritt 304
- 112 000 SEK /st exkl moms
- Additional information: solvent tank; Safety double jacket made of Fe (RSt-2; 4 mm) Volumetric volume (L): 10.000 L Pressure in tank: ATM - atmosferic Max. pressure (Bar): 0,50 Bar Max. temperature (°C): 50 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: no Documents included: no Technical…
- Lägg till i varukorg
-
-
-
- Tankar
13700 liter tank i Syrafast 316
- 175 000 SEK /st exkl moms
- Additional information: yeast tank in a brewery; Cone height approx. 1,300 mm Volumetric volume (L): 13.700 L Pressure in tank: ATM - atmosferic Max. pressure (Bar): 1 Bar Max. temperature (°C): 20 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Volume: 40 L Max Overpressure:…
- Lägg till i varukorg
-
-
-
- Tankar
3600 liter tank i Rostfritt 304
- 88 000 SEK /st exkl moms
- Additional information: brewery; 1 pipe inside the vessel (see photos); manhole approx. 345 x 440 mm; dents at the insulation jacket Volumetric volume (L): 3.600 L Pressure in tank: ATM - atmosferic Max. pressure (Bar): 2,60 Bar Max. temperature (°C): 20 °C Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank:…
- Lägg till i varukorg
-
-
-
- Tankar
2300 liter tank i Syrafast 316
- 31 000 SEK /st exkl moms
- Additional information: adhesive production; Total height incl. frame; frame Fe (lacquered); some residues of previous content Volumetric volume (L): 2.300 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: yes Documents included: no Technical drawing included: no Registration plate on the…
- Lägg till i varukorg
-
-
-
- Tankar
1280 liter tank i Syrafast 316
- 117 000 SEK /st exkl moms
- Additional information: Pressure Equipment Directive 97/23/EC Annex III Module H/H1 Material certificates 3.1 B Radiographic testing of weld seams (2%) Volumetric volume (L): 1.280 L Pressure in tank: ATM - atmosferic Max. pressure (Bar): 3 Bar Max. temperature (°C): 130 °C Material wet parts: SS AISI 316 (V4A) Model: vertical Configuration: insulated Heat exchanger: no Insulation: yes Mobile tank: no…
- Lägg till i varukorg
-
-
-
- Tankar
3120 liter tank i Rostfritt 304
- 99 000 SEK /st exkl moms
- Additional information: adhesive production; 1 reflux condenser is included in the scope of delivery (specified total height incl. reflux condenser); claws made of Fe; bent connections in the cylinder (see photos); some residues of previous content Volumetric volume (L): 3.120 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger:…
- Lägg till i varukorg
-
-
-
- Tankar
15600 liter tank i Rostfritt 304
- 80 000 SEK /st exkl moms
- Additional information: textile factory; some residues of previous content Volumetric volume (L): 15.600 L Pressure in tank: ATM - atmosferic Material wet parts: SS AISI 304 (V2A) Model: vertical Configuration: single-skin Heat exchanger: no Insulation: no Mobile tank: no Total discharge: no Documents included: no Technical drawing included: no Registration plate on the tank: yes Flange for agitator: no Position…
- Lägg till i varukorg
-
-
-
- Tankar
32000 liter tank i Rostfritt 304
- 337 000 SEK /st exkl moms
- item available on order Article type: brand new storage tank - type TZN-SL Volumetric volume (L): 32.000 L Max. density P (kg/m³): 1.200 Ra inner weld: 0,80 Finish stainless steel: 2B Pressure in tank: ATM - atmosferic Max. temperature (°C): 60 °C Min. temperature (°C): -10 °C Material wet parts: SS AISI 304L (V2A) Model: vertical Configuration: single-skin Heat exchanger:…
- Lägg till i varukorg
-
